Core Product Selling Points

Food-grade compliance: This is its core selling point, directly addressing the pain point of "material contamination" in the food and pharmaceutical industries. It can be used directly for conveying products such as biscuits, meat, and fruits and vegetables without the need for additional insulation layers.
High Customizability: Width, thickness, and pattern (such as plain, diamond, or herringbone) can be customized to meet specific needs. Guide strips, baffles, and skirts can even be added to accommodate different conveying angles (horizontal or inclined) and material types (bulk, lumps, or liquids).
Low noise and energy consumption: The belt's relatively soft texture reduces friction with the roller during operation, and its low weight reduces the load on the drive motor, indirectly saving energy.
Good Dimensional Stability: Low elongation (typically ≤1%) under long-term use and temperature fluctuations eliminates the need for frequent tensioning adjustments, ensuring accurate conveying. This makes it particularly suitable for conveying delicate materials such as electronic components.

Product	Model	Surface Material			Bottom Material			Thickness	Fabric layer	The minimum roller diameter	1%Nm extension	Unit weight kg/m²	Coefficient of friction	Operating Temperature	Maximum width of production
Product	Model	Surface Color	Surface Patterns	Surface Material	Bottom Color	Bottom Patterns	Bottom Material	Thickness	Fabric layer	The minimum roller diameter	1%Nm extension	Unit weight kg/m²	Coefficient of friction	Operating Temperature	Maximum width of production
Ordinary conveyor belt	H15U2-8Y/01	Yellow	Bright light	PU	White	Texture	PET	1.5	2	30	8	1.5	0.2	-20~+80	3000
	H15U2-8BG/02	Dark green	Sub-light	PU	White	Texture	PET	1.5	2	30	8	1.5	0.2	-20~+80	3000
	H15U2-8BK02-BK	Black	Sub-light	PU	White	Texture	PET	1.5	2	30	8	1.5	0.2	-20~+80	3000
	H20U2-8BG/02	Dark green	Sub-light	PU	White	Texture	PET	2	2	60	8	2.2	0.2	-20~+80	3000
	H30U2-8BG/02	Dark green	Sub-light	PU	White	Texture	PET	3	3	100	8	3.3	0.2	-20~+80	3000
	H40U3-12BG/02	Dark green	Sub-light	PU	White	Texture	PET	4	3	120	12	4.4	0.2	-20~+80	3000
	H15U2-8Y/02	Yellow	Sub-light	PU	White	Texture	PET	1.5	2	30	8	1.5	0.2	-20~+80	3000
	H20U2-8BK02-W	Black	Sub-light	PU	White	Texture	PET	2	2	60	8	2.2	0.2	-20~+80	3000
	S20U2-8BK02	Black	Sub-light	PU	White	Texture	PET	2	2	60	8	2.2	0.2	-20~+80	3000
	H15U1-BW/12	White	Straight stripes	PU	White	Texture	PET	1.5	2	30	6	1.3	0.2	-20~+80	3000
	H16U2-8BL/39	Blue	Texture	PU	White	Texture	PET	1.6	2	30	8	1.6	0.2	-20~+80	3000
	H12U2-8W/19	White	Texture	PU	White	Texture	PET	1.2	2	20	8	1.2	0.2	-20~+80	3000
	H15U2-8W/19	White	Texture	PU	White	Texture	PET	1.5	2	30	8	1.5	0.2	-20~+80	3000
	H18U2-8BL/03	Blue	Diamond Grain	PU	White	Texture	PET	1.8	2	40	8	1.6	0.2	-20~+80	3000
	H20U2-8W/03	White	Diamond Grain	PU	White	Texture	PET	2	2	60	8	1.8	0.2	-20~+80	3000
	H14U1-8CO/19	Brown	Texture	PU	White	Texture	PET	1.4	2	30	8	1.4	0.2	-20~+80	3000
	H15U2-4GY/16	Grey	Texture	PU	White	Texture	PET	1.5	2	20	8	1.5	0.2	-20~+80	1100
	H15U2-8BL/19	Blue	Small Diamond Grain	PU	White	Texture	PET	1.5	2	30	8	1.4	0.2	-20~+80	2000
	H13U2-8BL/D19	Blue	Texture	PU	White	Texture	PET	1.3	2	25	8	1.3	0.2	-20~+80	3000
	H15U2-8BL/D19	Blue	Texture	PU	White	Texture	PET	1.5	2	30	8	1.5	0.2	-20~+80	3000
Anti-static conveyor belt	H0BU1-4BG/02-HC8	Dark green	Sub-light	PU	White	Texture	PET	0.8	1	15	4	0.8	0.2	-20~+80	3000
	H10U1-4BK/02-HC8	Black	Sub-light	PU	White	Texture	PET	1	1	15	4	1	0.2	-20~+80	3000
	H10U1-4BG/02-HC8	Dark green	Sub-light	PU	White	Texture	PET	1	1	15	4	1	0.2	-20~+80	3000
	H14U2-8G02-BK-HC8	Apple green	Sub-light	PU	White	Texture	PET	1.4	2	30	8	1.4	0.2	-20~+80	3000
	H15U2-8BG02-BK-HC8	Dark green	Sub-light	PU	White	Texture	PET	1.5	2	30	8	1.5	0.2	-20~+80	3000
Temperature resistant conveyor bet	H14U1-8CO/19	Brown	Texture	PU	White	Texture	PET	1.4	2	30	4	2.2	0.2	-20~+80	3000
Temperature resistant conveyor bet	H20U2-8BK/02-HT	Black	Sub-light	PU	White	Texture	PET	2	2	60	8	2.2	0.2	-20~+120	2000
Food conveyor belt	H12U2-8W/19	White	Texture	PU	White	Texture	PET	1.2	2	20	8	1.2	0.2	-20~+80	3000
	H15U2-8W/19	White	Texture	PU	White	Texture	PET	1.5	2	30	8	1.5	0.2	-20~+80	3000
	H13U2-8BL/19	Blue	Texture	PU	Blue	Texture	PET	1.3	2	25	8	1.3	0.2	-20~+80	3000
	H15U2-8BL/19	Blue	Texture	PU	Blue	Texture	PET	1.5	2	30	8	1.5	0.2	-20~+80	3000
	S08U1-4W/02	White	Sub-light	PU	White	Texture	PET	0.8	1	15	4	0.8	0.3	-20~+80	3000
	H08U1-4Y/01	Yellow	Bright light	PU	White	Texture	PET	0.8	1	15	4	0.8	0.2	-20~+80	3000
	H12U2-8W/02	White	Sub-light	PU	White	Texture	PET	1.2	2	20	8	1.2	0.2	-20~+80	3000
	H15U2-8W/02	White	Sub-light	PU	White	Texture	PET	1.5	2	20	8	1.5	0.2	-20~+80	3000
	H15U2-8BL/02	Blue	Sub-light	PU	White	Texture	PET	1.5	2	30	8	1.5	0.2	-20~+80	3000
	H20U2-8W/01	White	Bright light	PU	White	Texture	PET	2	2	60	8	2.2	0.2	-20~+80	3000
	H20U2-8BL/01	Blue	Bright light	PU	White	Texture	PET	2	2	60	8	2.2	0.2	-20~+80	3000
	H30U3-12W/01	White	Bright light	PU	White	Texture	PET	3	3	100	12	3.3	0.2	-20~+80	3000
	H20U2-8BL/02	Blue	Sub-light	PU	White	Texture	PET	2	2	60	8	2.2	0.2	-20~+80	3000
	H15U1-4W/D02	White	Sub-light	PU	White	Texture	PET	1.5	2	30	8	1.5	0.2	-20~+80	3000
	N15U2-8FT/02	Transparent	Sub-light	PU	White	Texture	PET	1.5	2	30	8	1.5	0.2	-20~+80	3000
	H20U1-4W/02	White	Sub-light	PU	White	Texture	PET	2	1	50	4	2.2	0.2	-20~+80	3000
	H13U2-8CO/PTFE	Brown	Bright light	PU	White	Texture	PET	1.5	2	40	8	1.3	0.2	-20~+80	1000

Product Description

PU conveyor belts (polyurethane conveyor belts) are high-performance industrial belts. Their core advantages lie in their environmental friendliness, wear resistance, cleanliness, and ease of maintenance. Key selling points include "food-grade safety" and "customizable fit," making them widely used in industries such as food and electronics where hygiene and precision are critical.

Core Product Advantages

Environmentally friendly and safe material: The primary component is polyurethane, which is odorless and non-toxic. It does not contain harmful substances like plasticizers found in PVC, making it suitable for direct contact with food and pharmaceutical products and meeting international safety standards such as the FDA (U.S. Food and Drug Administration).

Strong wear and tear resistance: The belt structure is stable and its surface hardness is high, making it resistant to impact and friction, and it is not susceptible to cracking or damage. Its service life is 30%-50% longer than that of ordinary rubber conveyor belts (depending on the operating conditions).

Excellent temperature and chemical resistance: The typical operating temperature range is -20°C to 80°C, with some specialized models offering temperatures of -40°C to 120°C. It is also resistant to corrosion from common chemicals such as weak acids, bases, oils, greases, and alcohol, and is not susceptible to deformation or aging. Low cleaning and maintenance costs: The smooth, non-stick surface resists stains and requires only daily cleaning with water or a neutral detergent, eliminating the need for frequent disassembly and maintenance, thus reducing equipment downtime.

Automotive Industry

Application Areas
Specific Scenarios

Food Processing Industry: Biscuit production lines, meat cutting and conveying, fruit and vegetable washing and sorting, chocolate/candy conveying, baked goods cooling lines, etc.

Electronic and Electrical Industry: Circuit board assembly lines, electronic component (e.g., chips, resistors) conveying, and material handling in battery production

Pharmaceutical Industry: Conveying pharmaceuticals before packaging, medical device assembly lines, and material transfer within sterile workshops

Logistics and Packaging Industry: Conveying small items in express sorting centers, conveying automated packaging lines (e.g., cartons and bagged products)

Other Special Applications: Paper conveying in the printing industry, electrode conveying in lithium battery production, and lotion/paste filling lines in the cosmetics industry
